Surface profile data sampling points consistent interval
During the measurement process, the system can adjust the measuring speed of X-axis and the displacement of Z-axis in real time according to the slope of the measured contour, ensure the spacing of the sampling data points on X-axis of any slope of the measured contour is consistent.
The measured data can meet the basic requirement of "data intervals must be consistent" of the data processing algorithm for the point cloud data without any correction processing.
Z-axis real time, wide range measurement
The instrument makes impressive evolution from traditional stylus arc motion limitation, innovatively adopts vertical up-down motion trail. It realizes the real measurement of Z-axis coordinate points, effectively reduce measurement deviation caused by arc trail, to provide wider measurement range of Z-axis and improve measurement accuracy and applicability.
Highly adaptable to various industries
Quick clamping and measurement, workpiece not need pre-adjustment, significantly reduce placement and adjustment time. It is highly adaptable for bearings, lead screws, threads, guide rails and various field workpiece precision contour measurement.
With exceptional versatility, it can easily match measurement requirements of various industries.
